Multifunctional shield for Arduino boards
This learning shield for Arduino takes all the complexity of the hardware and reduces it to a simple interface. This is a modular circuit board with extra functionality.
The Arduino multifunctional shield is a perfect board for beginners, being useful to practice the operation of the basic components without using breadboards and wires, for example you can test the digital inputs/outputs, ADC channels.
The product is compatible with the Arduino Uno / Uno R3 and Arduino Mega 2560 range. The shield is placed on a UNO development board, taking care that the shield pins do not touch the USB connector of the UNO board; it is recommended to use an electrical insulating material (eg insulating tape) between them.
Hardware specifications:
• 3 Buttons
• 4 LEDs
• Header pins, connect to a serial communication module
• 7-segments CA display on 4 digits that controlled by two ICs 74HC595
• multiturn 10K potentiometer
• one piezo buzzer
Good luck experimenting! ✌
