Getting Started Elecrow CrowPanel 3.5 Inch

So far, if I want to try something or make a project related to ESP32 and TFT LCD Touchscreen, I use the ESP32 and TFT LCD Touchscreen modules separately and it takes up quite a lot of space and uses too many cables.

Then someone from Elecrow contacted me and offered me to try the "CrowPanel 3.5 Inch - HMI ESP32 Display 480x320 SPI TFT LCD Touch Screen" module. After I tried it, my impression is that the CrowPanel 3.5 Inch module is very good, because the ESP32 and TFT LCD Touch Screen are in one module, so it doesn't take up much space and doesn't require a lot of cables. Apart from that, it also provides several GPIO terminals, SD card slots and more.

The CrowPanel 3.5 Inch module is also compatible or supports Arduino IDE and LVGL, so it makes it easier for me or for some people who are used to using Arduino IDE and LVGL. In addition to supporting Arduino IDE and LVGL, it also supports Espressif IDF, PlatformIO, and Micro Python.

For those of you who want to start using the "CrowPanel 3.5 Inch - HMI ESP32 Display 480x320 SPI TFT LCD Touch Screen" module with Arduino and LVGL, I have made a video tutorial about it, please watch it here : https://www.youtube.com/watch?v=XR0dx-hrG4U .

Special thanks to Elecrow.

Thank you for visiting and reading my post. Hopefully this post is useful and can help you.

Sorry if my English is confusing, I was helped by "Google Translate".

Support and Subscribe to my YouTube channel : https://www.youtube.com/@utehstr (you can see other tutorials there).
Follow me on Instagram : https://www.instagram.com/utehstr/

Links
CrowPanel 3.5 Inch - HMI ESP32 Display 480x320 SPI TFT LCD Touch Screen : https://www.elecrow.com/esp32-display-3-5-inch-hmi-display-spi-tft-lcd-touch-screen.html?idd=5
Elecrow Wiki - CrowPanel ESP32 HMI 3.5-inch Display : https://www.elecrow.com/wiki/esp32-display-352727-intelligent-touch-screen-wi-fi26ble-320480-hmi-display.html
CrowPanel-ESP32-Display-Course-File : https://github.com/Elecrow-RD/CrowPanel-ESP32-Display-Course-File/tree/main/CrowPanel_ESP32_Tutorial
