ESP32-S3 1.69inch Cap Touch

ESP32-S3 1.69inch Cap Touch

  • thumbnail-img


Story



This project uses an 18pin 1.69" SPI capacitive touch lcd found on Alibaba or Aliexpress that has a resolution of 280 x 240. It uses an ESP32-S3-MINI-1-N8 that eliminates the hassle of tuning a chip of pcb track antenna.



I had a small amount of room on the board for a gyroscope but the i2c QwiiC connector will help of you want to add other sensors. Instead of a slide power button, the LTC2954ITS8 part uses a momentary pushbutton to turn on or off the board.



If you want to know more about the Code and PCB files



Please check it out on GitHub:



https://github.com/mike-rankin/ESP32-S3_1.69inch_Cap_Touch/tree/main?tab=readme-ov-file



(Reposted from Mike Rankin with permission)
