The Regular Custom PCB(On-line Ordering) service will provide you the PCB with the parameters shown in our this page. All the PCBs will be fully tested, not random test. And we suggest you to read the following files Read Me before Ordering and PCB Specification && FAQ before using our PCB service. If there is any problem for your order or any suggestion for our service, please contact us via PCB@elecrow.com, order@elecrow.com, techsupport@elecrow.com, qc@elecrow.com.
Gerber Files Required(2-layer) The following files would be needed for the PCB production: |
|||||
TOP LAYER: | pcbname.GTL | BOTTOM LAYER: | pcbname.GBL | ||
---|---|---|---|---|---|
Solder Stop Mask top: | pcbname.GTS | Solder Stop Mask Bottom: | pcbname.GBS | ||
Silk Top: | pcbname.GTO | Silk Bottom: | pcbname.GBO | ||
NC Drill: | pcbname.TXT | Mechanical layer: | pcbname.GML |
Gerber Files Required(4-layer) Including the layer shown in “Gerber Files Required(2-layer)”, and two inner layer should be added. |
|||
Inner1 layer: | pcbname.G1 | Inner2 layer: | pcbname.G2 |
---|
Specifications |
|||
Multi Layers: | 1-2-4-6-8 | PCB Material: | FR-4 |
---|---|---|---|
Available Color: | Green, Red, Yellow, Blue, White, Black, Matte Black, Purple | Silk Screen: | White, Black (For White and Yellow Solder Mask) |
Maximum Size: | 55cm X 55cm | Minimum Qty: | 5pcs |
Board Thickness: | 0.6mm,0.8mm, 1.0mm, 1.2mm, 1.6mm, 2.0mm | Thickness Tolerance: | (t≥1.0mm) ± 10% |
Thickness Tolerance: | (t<1.0mm) ± 0.1mm | Minimum PCB track: | 6mil (Recommend >8mil) |
Minimum Track Space: | 6mil (Recommend >8mil) | Minimum pads Space: | 8mil |
Minimum silkscreen text width: | 0.15mm | Minimum silkscreen text height: | 0.8mm |
Out Layer Copper Thickness: | 1oz(35um)/2oz(70um) | Inner Layer Copper Thickness: | 17um/35um |
Drilling Hole: | 0.3mm | Drill Diameter Tolerance (non-plated): | 0.05mm |
Drill Diameter Tolerance (plated): | 0.1mm | Outline Tolerance (Mechanical): | ±0.20mm |
Surface Finish: | HASL, HASL (Lead Free), ENIG |
Lead Time Example(Please make sure that you place the order before 5:30 p.m.(Beijing Time)) |
|||||
Order day | In production | 24H rush ship | 48H rush ship | 72H rush ship | 96H rush ship |
---|---|---|---|---|---|
Feb. 1st. | Feb. 2nd. | Feb. 3rd. | Feb. 4th. | Feb 5th. | Feb 6th. |
Special Requirement |
|
1 | For one layer PCB, we make it as 1 layer with mask one side in default. Please leave a comment if it should be made as 1 layer with mask both sides. |
---|---|
2 | Board outline must be included at least in one layer if there isn't GML/GKO layer. |
3 | Gerber “RS-274-X” is the sole format for fabrication, and you can output gerber from other formats, they are “BRD”, “PCBdoc”, “LAY6”. |
4 | If you need some holes not plated, please name the non-plated holes as pcb.name-NPTH.txt and leave a comment. |
5 | For stencil, we skip through-hole component pads and all drills (holes) by default except the fiducial, so you need to leave a message to us if you need to make the holes of the GTP and GBP. |
6 | If you want to make your board with golden finger and beveled edge or edge copper plating, please leave us a comment or contact us in PCB@elecrow.com. And you may need to pay extra for it. |
7 | We could make the PCB without any surface finish and leave the copper exposed, please leave us a comment in your order. |
8 | For panelizing , we could make your board with v-cut or mouse bite. You can know more about how to reduce cost with panelizing service on this page. |
9 | The engineer will add manufacture time code on the board edge. If any code is not needed, please leave a comment. |
10 | The $1 USD PCB prototype is to encourage innovation, please don't add same PCB design with this $1 USD PCB prototype. |
